Euromac offers the Digibend as an alternative to a conventional press brake. These Euromac bending machines are suitable for small parts and thick materials. Our horizontal bending machines give unlimited bending capabilities, this includes bending flat bar, copper busbar, tube, punching, shearing, straightening and many other applications.
Here at Cotswold Machinery Sales Ltd we have over the last 30 years designed and manufactured special tooling for the Euromac Digibend to compliment the standard range available. All machines in the Euromac Digibend range can come equipped with an easy to use control system (2 axis CNC controlled) which makes it incredibly flexible.
All Digibend tables are machined out of a single monoblock of Meehanite 700N/mm². The cylinder is completely embraced in the structure and the RAM is guided in all of its stroke. This maintains the highest accuracy and repeatability (0.05 mm) even after thousands of bends.
|Max. pressure (kN)||200|
|Max. stroke (mm)||195|
|Max. working speed (mm/sec)||9.6|
|Min. working speed (mm/sec)||4.8|
|Return speed (mm/sec)||48|
|Average working speed (mm/sec)||28.8|
|Sequence of storables programs||50|
|Number of bends for each sequence||16|
|Working table dimensions (mm)||480 x 1060 x 925 (H)|
|Fixing holes in working table (nr. x Ø - mm)||1 x Ø 80 / 2 x Ø 50|
|Working height (mm)||925|
|Oil tank capacity (lt.)||40|
|Motore HP - Kw||3 - 2|
|High bending (mm)||H=200|
|Extra high bending (mm)||/|
|Shearing max thickness||H=150 x 10 (th)|
|Punching max thickness||Ø 30 x 5 (th)|
|Two-jaw-bending (mm)||Ø 42|
|Rotary bending (mm)||Ø 50|
|CNC automatic backguage (Length, mm)||NO|
|Approx. weight (kg)||340|
|Overall dimensions (L x l x h)||580 x 1060 x 1150|
All application range indications are referred to steel material with 400N/mm2 resistance.
