- Machines compliant to 2006/42/CE standard
- Bending rolls independently adjustable, for double pre-bending capability on the leading and trailing end of symmetrical profiles
- 3 driving rolls to guarantee maximum drive on the profile
- Lateral guide rolls with three-dimensional adjustment
- Standard bending rolls of alloy steel, heat treated to surface hardness 60 HRC
- Modular rolls that allow the bending of most profiles
- Free standing remote control station to control the machine in safety
- Possibility to install the machine both in vertical and horizontal position
- Torque limiter installed on top roll shaft
- One-piece fabricated steel frame
- Shaft and pinions installed on high dynamic load roller bearings
- Gears coupled directly on splined shaft
- Water based environmental friendly paint
Rated for a section modulus of 100 to 160 cm³, the Serie 3000 Model 309 has a 155 mm upper shaft and a 135 mm lower shaft, with 430 mm rolls and an 18.5 kW drive. Weight is 6700 kg and the rolling speed is 0 to 7 m/min. As with the rest of the range, the standard bending rolls are made from alloy steel heat treated to 60 HRC, and modular rolls let the machine take most profiles. Shafts and pinions sit on high dynamic load roller bearings.
