- Machines compliant to 2006/42/CE standard
- Bending rolls independently adjustable, for double pre-bending capability on the leading and trailing end of symmetrical profiles
- 3 driving rolls to guarantee maximum drive on the profile
- Lateral guide rolls with three-dimensional adjustment
- Standard bending rolls of alloy steel, heat treated to surface hardness 60 HRC
- Modular rolls that allow the bending of most profiles
- Free standing remote control station to control the machine in safety
- Possibility to install the machine both in vertical and horizontal position
- Torque limiter installed on top roll shaft
- One-piece fabricated steel frame
- Shaft and pinions installed on high dynamic load roller bearings
- Gears coupled directly on splined shaft
- Water based environmental friendly paint
The Serie 3000 Model 315 is the largest machine in the range, with a section modulus of 1300 to 2800 cm³. Its shaft diameter is listed as 360 mm and its rolls measure 790 mm. A 90 kW drive gives a rolling speed of 0 to 7 m/min, and the machine weighs 42,000 kg. It can be installed in a vertical or horizontal position, is controlled from a free-standing remote control station, and is compliant with the 2006/42/CE standard.
